CONSTRUCTION / FURNITURE SCREW

Size

Thread #6~#10 (M3.5~M4.8)

Length 1/2"~8" (13mm~200mm)

Head Type

Bugle, Wafer, Flat, Pan framing...

Recess

Phillips, Pozi, Square...

Thread

Fine thread (Type SS, Type 2A), Coarse thread...

Point

Sharp point

EN CE 14566 available

Head Type

Pan head, Flat / Countersunk head, Oval head, Hex head...

Recess

Phillips, Pozi, Torx, Slot, Square, Combo...

Thread

60 Degree thread(Full size body, Single thread, 2A)

Point

Sharp point

Size

Thread M2.5~M10

Length 10mm~400mm

Head Type

Pan head, Double countersunk flat head, Oval head...

Recess

Phillips, Pozi, Torx, Square, Combo...

Thread

40 Degree thread, Milling ribs+Saw thread...

Point

Sharp point, Type 17

CE EN 14592 available

Size

Thread #6 to #12

Length 3/8" to 6"

Head Type

Pan head, Flat Countersunk head, Oval head, Modified Truss head ...

Recess

Phillips, Pozi, Torx, Square, Combo...

Thread

45 / 60 Degree thread, 45 Degree Unsymmetrical thread(30°&15°)

Point

Sharp point, Type 17

Size

Thread 3/16, 1/4 (M6.3), or M7.5

Length 3/8" to 6", or 52mm to 222mm

Head Type

Cylinder head, Flat Countersunk head, Ind. Hex Washer head...

Recess

Phillips, Pozi, Torx, Slot, Combo...

Thread

Hi-Lo thread cut 3 notches

Point

Diamond point, Needle point
